C
LEAR
P
ATH
-SC
U
SER
M
ANUAL
R
EV
.
1.36
8
T
EKNIC
,
I
NC
. T
EL
.
(585)
784-7454
P
ARTS OF A
C
LEAR
P
ATH
-SC
M
OTOR
Industry-leading, programmable, brushless servo motor with precision
optical encoder, built in controller, trajectory generator, servo
compensator, and torque drive.
Diagnostic Port
(USB micro-B)
DC Bus Power Connector
(Molex Minifit Jr. 4 position)
Auxilliary PE
(Protective Earth)
Connection Point
ClearPath I/O Connector
(Molex Minifit Jr. 8 position)
Stainless
Steel Shaft
NEMA
Mounting
Flange
Die Cast
Heatsink
Sealing
Gasket
Housing
(Anodized aluminum)
Keyway
Status LED
Silicone Plug
(Covers diag. port)
Parts of a ClearPath-SC motor
