M OUNTING D IMENSIONS : C LEAR P ATH -SC NEMA 23
[L
2.54]
L
.100
1.90±0.10 .075±.004
37.68 1.483
9.533 9.500
.3753 .3740
3
.118
20.58±0.76
.810±.03
3
.118
12
.472
44.45 1.750
10.82
.426
Recommended Clearance for USB Access
6.358 6.325
.2503 .2490
20.57
.810
Optional 1/4" Full Round Shaft
Note: Shaft key not included with motor Key available through McMaster-Carr Part Number: 96717A086 Description: Metric shaft key Dimensions: 3mm x 3mm x 10mm
Model Number
“L” Dimension
CPM-_ _ _ _ -2310_ - _ _
84.81 [3.339]
CPM-_ _ _ _ -2311_ - _ _
84.81 [3.339]
CPM-_ _ _ _ -2321_ - _ _
103.83 [4.088]
CPM-_ _ _ _ -2331_ - _ _
122.83 [4.836]
CPM-_ _ _ _ -2341_ - _ _
141.83 [5.584]
59.10±0.76 2.327±.030
53.85 2.120
81.85±0.76
3.222±.03
I/O Connector
Power Connector
4x
5.20
.205
THRU
32
1.260
32
1.260
4x
3.18
.125
For #6 or M3.5
thread-cutters. Use to mount optional 40mm x 40mm fan
66.68
2.625
38.10
-
0 0.051
1.500
+
-
.000 .002
1/4” shaft svailable
231x and 232x
models only
Shaft Keyway Detail
[12]
.472
[3]
.118
[1.80]
.071
[3]
.118
