C
LEAR
P
ATH
-SC
U
SER
M
ANUAL
R
EV
.
1.36
93
T
EKNIC
,
I
NC
. T
EL
.
(585)
784-7454
M
OUNTING
D
IMENSIONS
:
P
OWER
H
UB
77.72
3.060
3.18
.125
74.55
2.935
104.65
4.120
3.18
.125
101.47
3.995
Ø
.155 ±.004 3.94 ±0.10 THRU
78.38
3.086
w/ connector
overhang
27.06
1.065
1.55
.061
6.35
.250
Power Hub Mounting Dimensions
