Preparation for Use- 2215A Operators
CAUTION
FOR CONT IN UEO FI RE PROTECTION
R EPLACE ONLY W IT H SPECIFI ED
lYPE ANO RATED FUSED IS CO NNE CT
POW ER I NPUT BEFORE REP L AC IN G FUSE
POWER
M AX WATTS 40
MAX VA 70
FREQ 48 - 440 Hz
FUSE 2SOV
LIN E
FUSE
EXT Z AX IS INPUT
þÿ10k© POSITIV E GOI NG
IN PUT DECREASES
IN TE NS ITY
5 VOLT p-p CAUSES
NOTICEABLE
M ODULA TI ON AT
NORMAL I NTENSIT Y.
<=30V PEAK
TEKTRONIX INC , BEAVERTON OREGON, U $
POWER
CORD
C4207 ·03
Figure 2-2. Fuse holder and power cord connector.
2-2
INSTRUMENT COOLING
Always maintain adequate instrument cooling. The venti-
lation holes on both sides of the instrument cabinet and on
the rear panel must remain free
of obstruction.
