Tektronix 2465B Service Manual

Component Tektronix Serial No. Name & Description
Number Part No. Effective Dscont
Mfr. Mfr. Part No.
Code
A9R4374
A9R4375
A9R4376
A9R4377
313-1163-00
313-1220-00
313-1101-00
322-3469-00
RES,FXD,FILM:16K OHM,5%,0.2W
RES,FXD,FILM:22 OHM,5%,0.2W
RES,FXD,FILM:100 OHM,5%,0.2W
RES,FXD,FILM:750K OHM.1 %,0.2W,TC=T0
91637 CCF50-2-16001J
91637 CCF50-2-22R00J
91637 CCF50-2-100R0J
91637 CCF501G75002F
A9R4378
A9R4379
A9R4380
A9R4381
A9R4391
322-3492-00
313-1153-00
307-0412-00
322-3239-00
307-0381 -00
RES,FXD,FILM:600K OHM.1 %,0.2W,TC=TO
RES,FXD,FILM:15K,5%,0.2W
RES NTWK,FXD,FI:25M OHM,1%,0.5W
RES,FXD,FILM:3.01KOHM,1%,0.2W,TC=T0
RES,FXD,FILM:4.99 MEG OHM,1%,0.5W
91637 CCF501G60002F
91637 CCF50-2-15001J
64537 FL1/2 25m+/-
91637 CCF501G30100F
64537 FL 1/2 4.99 M +
A9R4401
A9R4402
A9R4403
A9R4404
A9R4405
313-1911-00
313-1101-00
313-1823-00
313-1512-00
315-0101-03
RES,FXD,FILM:910 OHM,5%,0.2W
RES,FXD,FILM:100 OHM,5%,0.2W
RES,FXD,FILM:82K OHM,5%,0.2W
RES,FXD,FILM:5.1KOHM,5%,0.2W
RES,FXD,CMPSN:100 OHM,5%,0.25W
91637 CCF50-2-910R0J
91637 CCF50-2-100R0J
91637 CCF50-2-82001J
91637 CCF50-2-51000J
01121 CB1015
A9R4410
A9R4411
A9R4412
A9R4413
A9R4414
313-1204-00
322-3329-00
313-1331-00
315-0101-03
322-3335-00
RES,FXD,FlLM:200K,5%,0.2W
RES,FXD,FILM:26.1KOHM.1%,0.2W,TC=T0
RES,FXD,FILM:330 OHM,5%,0.2W
RES,FXD,CMPSN:100 OHM,5%,0.25W
RES,FXD,HLM:30.1KOHM,1%,0.2W,TC=T0
91637 CCF50-2-20002J
91637 CCF501G26101F
91637 CCF50-2-330ROJ
01121 CB1015
91637 CCF501G30101F
A9R4415
A9R4416
A9R4421
A9R4422
A9R4430
322-3277-00
313-1132-00
313-1201-00
313-1101-00
311-2296-00
RES,FXD,FILM:7.5K OHM,1%,0.2W,TC=T0 91637
RES,FXD,FILM:1.3K OHM,5°/o,0.2W 91637
RES,FXD,FILM:200 OHM,5%,0.2W 91637
RES,FXD,FILM:100OHM,5%,0.2W 91637
RES,VAR,WW:TRIMMER,2.5 MEGOHMS.0.5W 32997
CCF501G75000F
CCF50-2-13000J
CCF50-2-200R0J
CCF5O-2-100R0J
3386N-HV2-255
A9R4431
A9R4432
A9R4433
A9R4434
A9R4435
307-1265-00
313-1153-00
321-1720-00
307-0381 -00
322-3402-00
RES,FXD,FILM:13M OHM,5%,0.5W 64537
RES,FXD,FILM:15K,5%,0.2W 91637
RES,FXD,FILM:3.24M OHM,1%,0.125W,TC=T0 91637
RES,FXD,FILM:4.99 MEG OHM,1%,0.5W 64537
RES,FXD:METAL FILM;150K OHM,1%,0.2W,TC = 100 91637
FL1/2 13MOHM
CCF50-2-15001J
CMF55116G32403F
FL 1/2 4.99 M +
CCF50G15002F
A9R4440
A9R4441
A9R4442
A9R4443
A9R4450
307-1264-00
307-1264-00
307-1264-00
322-3392-00
322-3443-00
RES,FXD,FILM:10M OHM,0.5%,0.5W
RES,FXD,FILM:10M OHM,0.5%,0.5W
RES,FXD,FILM:10M OHM,0.5%,0.5W
RES,FXD,FILM:118K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:402KOHM,1%,0.2W,TC=T0
64537
64537
64537
91637
91637
FL-1/2 10M+/-
FL-1/2 10M +/-
FL-1/2 10M +/-
CCF501G11802F
CCF501G40202F
A9R4451
A9R4452
A9R4453
A9R4454
A9R4460
321-0510-00
313-1102-00
313-1102-00
313-1433-00
322-3327-00
RES,FXD,FILM:2.00M OHM,1%,0.125W,TC=T0 91637
RES,FXD,FILM:1K OHM,5%,0.2W 91637
RES,FXD,FILM:1 K OHM,5%,0.2W 91637
RES,FXD,FILM:43K,5%,0.2W 91637
RES,FXD,FILM:24.9K OHM,1%,0.2W,TC=T0 91637
CMF55116G20003F
CCF50-2-10000J
CCF50-2-10000J
CCF50-2-43001J
CCF50-2-G24901F
A9R4461 322-3402-00
RES,FXD:METAL FILM;150K OHM,1%,0.2W,TC=100 91637
CCF50G15002F
9-68
REV JAN 1993
2467B Replaceable Electrical Parts

Tektronix 2465B Specifications

General

Bandwidth	400 MHz
Channels	4
Vertical Sensitivity	2 mV/div to 5 V/div
Maximum Input Voltage	400 V (DC + peak AC)
Display	CRT
Trigger Modes	Auto, Normal, Single
Time Base Range	500 ps/div to 0.5 s/div
Rise Time	875 ps
Power Supply	48 to 440 Hz
Dimensions	495 mm
