NOTE. For the MSO58LP, the AUX In external trigger input only supports Edge triggering.
NOTE. To trigger on a bus, you must first add the bus to the Waveform view. See Add a math, reference, or bus waveform
on page 93
NOTE. Triggering on buses other than Parallel requires purchasing and installing serial trigger and analysis options. See the
Tektronix Web site for available serial trigger and analysis options.
3. Select the other fields and panels to refine the trigger conditions. The menu fields and trigger graphic update as you make
changes to the trigger settings. Displayed fields depend on the selected trigger type. Selection changes take effect
immediately.
