Tektronix 5 Series MSO Printable Help

Parallel serial bus trigger settings panel
NOTE. Parallel bus triggering is standard on all instruments.
Field or control Description
Source Select the type of information on which to trigger.
Data Sets the data pattern on which to trigger. The number of bits shown depends on how the
parallel bus is defined.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 363
