Tektronix 5 Series MSO Printable Help

Settings panel (Timeout Trigger configuration menu) fields and controls.
Field or control Description
Source Lists the source channel or waveform to use to trigger or search. Types that require multiple
inputs will replace this control with a different source definition control.
Trigger When
■
Stays High: The signal stays above the specified threshold level longer than the specified
time.
■
Stays Low: The signal stays below the specified threshold level longer than the specified
time.
■
Either: The signal stays above or below the specified threshold level longer than the
specified time.
Threshold Sets the amplitude level that the signal must pass through to be considered a valid transition.
Set to 50% Sets the threshold at 50% of the measured signal transition range. 50% is calculated as (Top +
Bottom)/2.
Time Limit Sets the time period condition to be met.
Logic Qualification When set to On, enables logic qualification to further refine the trigger condition by setting the
required logic conditions on the source signals to generate a trigger event.
Define Inputs Opens the Logic Qualification - Define Inputs configuration menu. Use this menu to set the
logic state, threshold levels, and logic operation of the input signals. See Logic Qualification -
Define Inputs configuration menu on page 400.
Available when Logic Qualification = On.
Menus and dialog boxes
398 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
