Trigger Setup
3. Push Type.
Type
Bus
Source Bus
B1 (I2C)
Trigger On
Address
Address
07F
Direction
Write
Mode
Auto
& Holdoff
4. Turn multipurpose knob a to scroll through the
list of trigger types until you select Bus.
B1 (I2C)
5. Push Sour ce Bus and turn multipurpose kno b
a to scroll through the source bus side menu
until you select the bus that you w ant to trigger
on.
B2
(Parallel)
136 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
