Preface
Preface
This manual describes the installation and operation of DPO7000 Series, DSA70000/B Series and DPO70000/B Series
Instruments. Basic operations and concepts are presented in this manual. For more detailed information see the online help
on your instrument. The following instruments are supported by this manual:
DPO72004/B and DSA72004/B
DPO71604/B and DSA71604/B
DPO71254/B and DSA71254/B
DPO70804/B and DSA70804/B
DPO70604/B and DSA70604/B
DPO70404/B and DSA70404/B
DPO7354
DPO7254
DPO7104
DPO7054
Key Features
DPO7000, DSA70000/B and DPO70000/B Series Instruments can help you verify, debug, and characterize electronic
designs. Key features include:
20 GHz bandwidth and 50 GS/s real time sampling rate on all channels, DPO72004/B and DSA 72004/B
16 GHz bandwidth and 50 GS/s real time sampling rate on all channels, DPO71604/B and DSA 71604/B
12.5 GHz bandwidth and 50 GS/s real time sampling rate on all channels, DPO71254/B and DSA71254/B
8 GHz bandwidth and 25 GS/s real time sampling rate on all channels, DPO70804/B and DSA70804/B
6 GHz bandwidth and 25 GS/s real time sampling rate on all channels, DPO70604/B and DSA70604/B
4 GHz bandwidth and 25 GS/s real time sampling rate on all channels, DPO70404/B and DSA70404/B
3.5 GHz bandwidth and 10 GS/s real time sampling rate on all channels, 40 GS/s on 1 channel, DPO7354
2.5 GHz bandwidth and 10 GS/s real time sampling rate on all channels, 40 GS/s on 1 channel, DPO7254
1 GHz bandwidth and 5 GS/s (10 GS/s optional) real time sampling rate on all channels, 20 GS/s (40 GS/s optional)
on 1 channel, DPO7104
500 MHz bandwidth and 2.5 GS/s (5 GS/s optional) real time sampling rate on all channels, 10 GS/s (20 GS/s optional)
on 1 channel, DPO7054
Enhanced Bandwidth capability that, when enabled, applies Digital Signal Process (DSP) filters that can extend the
bandwidth and flatten the passband. Enhanced Bandwidth provides a matched response across enabled channels
when they are at maximum
sample rate. You can limit the bandwidth in 1 GHz increments down to 500 MHz for
maximum bandwidth to optimize the signal to noise ratio. E nhanced bandwidth is extended to the probe tip for some
high performance probes and tips.
