Getting Acquain
ted with Your Instrument
Side and Rear P anels
1. USB ports
2. Video port to c
onnect a monitor for
side-by-side display
NOTE. Some instruments may have
additional a
udio connectors.
3. Mic connector for microphone
4. Line Out connector for speaker
5. Scope Only XGA Out video port to
connect a m
onitor
6. Printer co
nnection
7. Line In con
nector
8. RJ-45 LAN
connector to connect to
network
9. Centronics Parallel Port
10. COM 1 serial port
11.
PS-2 connector for mouse
12.
PS-2 connector for keyboard
13. Rear speaker out
14. S ide speaker out
15. CTR Bass speaker
16. TekLink connector for future use
17. Removable hard disk drive
18. G PIB port to connect to controller
19. A u xiliary output
20. Channel 3 output
21. External reference input
<4 G
Hz models
14 DPO7000 Series and DPO /DS A70000/B Series Quick Start User Manual
