Tektronix DPO7054C Printable Help

■
Opt. USB - USB 2.0 Compliance Testing
■
Opt. USBHSIC - USB2.0 and HSIC Bundle, includes options Opt. DJA, HSIC, SR-USB, and USB
■
Opt. USBPWR - USB Power Adapter/ EPS Compliance Automated Test Solution
■
Opt. VNM - CAN/LIN Protocol Analysis Software
■
Record Length:
■
Opt. 5RL - 50 MSamples/ch, 125M maximum for 1 ch and 2 ch
■
Opt. 10RL - 125 MSamples/ch, 250M maximum for 1 ch and 2 ch
DPO7000C
■
Hardware:
■
Opt. 2SR (available only on DPO7104C instruments) - Double maximum real time sample rate
■
Record Length:
■
Opt. 5RL - 250 MSamples max, 50 MSamples/ch
■
Opt. 10RL - 500 MSamples max, 125 MSamples/ch (Only available on DPO7254C/DPO7354C instruments)
■
Service:
■
Opt. R3 - Repair service 3 years, including warranty
■
Opt. R5 - Repair service 5 years, including warranty
■
Software:
■
Opt. BRR - BroadR-Reach Compliance Testing
■
Opt. DDRA - DDR Memory Bus Analysis (requires DJA)
■
Opt. DJA - Jitter And Eye Analysis Tools - Advanced (DPOJET)
■
Opt. ET3 - Ethernet Compliance Test
■
Opt. D-PHY - MIPI
®
D-PHY Characterization and Compliance Testing
■
Opt. HSIC - USB HSIC protocol decode and electrical validation (For models of bandwidth ≥2.5 GHz only.) (requires DJA)
■
Opt. LSA - Low Speed Serial Analysis (CAN/LIN trigger)
■
Opt. MOST – MOST Essentials – Electrical Compliance and Debug Test Solution for MOST50 and MOST150
■
Opt. MTM - Serial Communications Mask Testing
■
Opt. PWR - DPOPWR Power Measurement and Analysis
■
Opt. PS2 - Power Solution Bundle: DPOPWR, THDP0200, TCP0030A, 067-1686-XX (Deskew Fixture)
■
Opt. PS3 - Power Solution Bundle: DPOPWR, TMDP0200, TCP0020, 067-1686-XX (Deskew Fixture)
■
Opt. SR-AERO - MIL-STD-1553 Serial Triggering and Analysis
■
Opt. SR-AUTO - Automotive Serial Triggering and Analysis (CAN, LIN, FLEXRAY)
■
Opt. SR-COMP - Computer Serial Triggering and Analysis (RS-232/422/485/UART)
■
Opt. SR-CUST - Custom Serial Analysis Kit for Developers
■
Opt. SR-DPHY - MIPI-D-PHY (DSI1/CSI2) Serial Analysis
■
Opt. SR-EMBD - Embedded Serial Triggering and Analysis (I2C, SPI)
About Tektronix oscilloscopes
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 11
