Behavior. Measurements are updated approximately three times a second, or less for long record lengths. Measurements are
calculated after each acquisition. You can display up to eight automatic measurements.
TIP. Select the individual measurements directly from the Measure menu Histogram Measurements submenu.
What do you want to do next?
Learn about taking amplitude measurements.
Learn about taking timing measurements.
Learn about other measurements.
Learn about communications measurements.
Learn more about the Measurements list.
Learn more about the Measurement controls.
Waveform count
Displays the number of waveforms that have contributed to the histogram.
Hits in Box
Displays the number of points in or on the histogram box.
Peak Hits
Displays the number of points in the largest bin of the histogram.
Median
The middle point of the histogram box. Half of all acquired points within or on the histogram box are less than this value and half
are greater than this value.
Histogram Max
Displays the voltage of the highest nonzero bin in vertical histograms or the time of the rightmost nonzero bin in the horizontal
histograms.
Histogram Min
Displays the voltage of the lowest nonzero bin in vertical histograms or the time of the leftmost nonzero bin in the horizontal
histograms.
Pk-Pk
Displays the peak-to-peak value of the histogram.
â–
Vertical histograms display the "voltage" of the highest nonzero bin minus the "voltage" of the lowest nonzero bin.
â–
Horizontal histograms display the "time" of the rightmost nonzero bin minus the "time" of the leftmost nonzero bin.
Histogram Mean
Measures the average of all acquired points within or on the histogram box.
StdDev (standard deviation)
The standard deviation (Root Mean Square (RMS) deviation) of all acquired points within or on the histogram box.
Mean±1 StdDev
The percentage of points in the histogram that are within one standard deviation of the histogram mean.
Oscilloscope reference
796 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
