Commands Listed in Alphabetical Order
Arguments
CH<x> selects a
channel waveform as the source for the histogram. The range
for x is 1 through 8.
MATH<x> selects a math waveform as the source for the histogram. The range
for x is 1 through 8.
REF<x> selects a reference waveform as the source for the histogram. The
range for x is 1 through 8.
MAIn (optional) selects Main as the timebase for the histogram display.
MAG1 (optional) selects MAG1 as the timebase for the histogram display.
MAG2 (optional) selects MAG2 as the timebase for the histogram display.
Examples
HISTOGRAM:SOURCE CH1 enables the Channel 1 waveform to be compared
against the histogram box. The default timebase, Main, is used for the histogram
display.
HISTOGRAM:SOURCE? might return HISTOGRAM:SOURCE CH1,MAG1, indicating
that the waveform for Channel 1 is the source for the histogram and that it is
displayed using MAG1 as the timebase.
HIStogram:STATistics? (Query Only)
This query only command ret
urns all h istogram statistics. These are the Histogram
statistics that are displayed in the Histogram readout:
Mean
Median
Std Dev
Pk-Pk
µ±1s
µ±2s
µ±3s
Peak
Hits
Waveforms
The histogram statistics (and count) can be reset with the HIStogram:COUNt
command.
Group
Histogram
2-148 DSA/CSA/TDS8X00/B Series Programmer Manual
