Tektronix DSA8200 Series User Manual

Appendix C: Factory D efault Setup Values
The following tables list the default setup values by command group. These
are the values that the instrument sets w hen you press the DEFAULT SETUP
front-panel
button or send the FACtory command. Only those commands that
have values set by the DEFAULT SETUP function are listed in these tables.
Acquisition Default Values
The following table lists the Acquisition factory defaul
t setup values.
Command Default Values
ACQuire:MODe SAMPLE
ACQuire:NUMAVg
16
ACQuire:SAVEFile:SAVEScreen
““
ACQuire:SAVEFile:SAVEWfm
““
ACQuire:STATE 1(ON)
ACQuire:STOPAfter:ACTion NONE
ACQuire:STOPAfter:BELL 0(OFF)
ACQuire:STOPAfter:CONDition ACQ WFMS
ACQuire:STOPAfter:COUNt
1
ACQuire:STOPAfter:MODe RUNSTOP
Cursor Default Values
The following table lists the C ursor factory de fault setup values.
Command Default Values
CURSor:CURSor<x>:COLOR
5
CURSor:CURSor<x>:SOUrce CH1,MAIN
CURSor:FUNCtion 0(OFF)
CURSor:HBArs:POSition<x> Cursor 1 = -1.621616E-001
Cursor 2 = 1.702702E-001
CURSor:SELect NONE
CURSor:VBArs:POSition<x> Cursor 1 = 1.965E-008
Cursor 2 = 2.130E-008
CURSor:WAVeform:POSition<x> Cursor 1 = 1.965E-008
Cursor 2 = 2.130E-008
Display Default Values
The following table lists the Display factory default setup values.
Command Default Values
DISplay:COLor:BACKground 0 (black)
DISplay:COLor:CURSor<x> Cursor 1 = 5 (red)
Cursor 2 = 5 (red)
DSA/CSA/TDS8X00/B Series Programmer Manual C-1
