Command Groups
The DSA8200 programmable interface conforms to Tektronix standard codes
and formats except where noted. The GPIB interface als o conforms to IEEE
Std 488.2-19
87 except where noted.
Acquisition Command Group
Use the commands in the Acquisition Command Group to set up the modes and
functions that control how the instrument acquires the signals you input to the
channels and processes them into waveforms.
Using these commands for acquiring waveforms, you can do the following:
Start and stop acquisitions.
Control whether each waveform is simply acquired, averaged, or enveloped
over successive acquisitions of that waveform.
Set the controls or conditions that start and stop acquisitions.
Determine the action the system takes upon completing an acquisition, such
as saving all waveforms and taking a me
asurement when the acquisition is
stopped.
Get data on acquired waveforms, histograms, and masks.
Get acquisition parameters.
Clear all acquired data.
Table 2-18: Acquisition Commands
Command Description
ACQuire?
Returns acquisition parameters
ACQuire:CURRentcount:ACQWfms? Returns acquired waveforms count
ACQuire:CURRentcount:HISTHits?
Returns histogram hits count
ACQuire:CURRentcount:HISTWfms? Returns histogram waveforms count
ACQuire:CURRentcount:MASKHits<x>?
Returns mask hits count
ACQuire:CURRentcount:MASKSamples?
Returns mask samples count
ACQuire:CURRentcount:MASKTHits?
Returns total mask hits count
ACQuire:CURRentcount:MASKWfms? Returns mask waveforms count
ACQuire:DATA:CLEar Clears all acquired data
ACQuire:MODe Sets or returns acquisition mode
ACQuire:NUMAVg Sets or returns number of acquisitions for an
averaged waveform
ACQuire:SAVEFile:SAVEScreen Sets or returns the file to save screen to on
acquisition stopped
DSA/CSA/TDS8X00/B Series Programmer Manual 2-13
