Command Groups
Command
Description
TRIGger:PSYNc:TRIGProbe:PLENgth Sets or returns the pattern length for the
probe connector
TRIGger:SETLevel Sets the trigger level to 50% of the applied
signal
TRIGger:SL
Ope
Sets or retu
rns the trigger slope
TRIGger:SO
Urce
Sets or retu
rns the trigger source
TRIGger:S
TATE?
Returns the trigger system status
Vertical Command Group
You use the commands in the Vertical Command Group to control the vertical
setup of all live (channel) waveforms for acquisition and to control the display of
channel, reference, and math waveforms. This group contains commands to set
up the vertical parameters for either electrical or optical signals, depending on
the sam
pling module in use.
You can use the commands in this group to do the following:
Enable or disable the display of any channel, math, or reference waveform.
Set w hich waveform is affected by the front-panel controls.
Set the vertical scale for each channel.
Set the vertical position. The vertical position affects only the display position
of a channel, math, or reference waveform.
Set the offset value to shift the vertical acquisition window to match the
waveform data that you want to acquire (affects only channels).
DSA/CSA/TDS8X00/B Series Programmer Manual 2-41
