Command Groups
Command
Description
TRIGger:AUTOSync:DCR A tio Sets or returns the AutoS ync option for
data-to-clock ratio selection (on or off)
TRIGger:AUTOSync:PLENgth Sets or returns the AutoS ync option for
pattern leng
th selection (on or off)
TRIGger:CH
<x>:CLKRec:LIST?
Returns a li
st of available clock recovery
selections per channel
TRIGger:CH<x>:CLK Rec:RANge Returns the allowable range of user clock
recovery rates for the module containing
CH<x>
TRIGger:
CH<x>:CLKRec:USE r
Sets a use
r (custom) clock recovery rate
to be a s peciļ¬ed value within an allowable
range, which is module-dependent
Returns t
he rate currently deļ¬ned as the
user clock recovery rate
TRIGger:CH<x>:CLKRec:VALue Sets or returns the clock recovery value for
the speciļ¬ed channel
TRIGger:CLKRec:SOUrce Sets or returns the clock recovery channel
source
TRIGg
er:GATEd
Sets o
r returns the gated triggering (on or off)
Requires Option GT
TRIGger:HIFreq Sets or returns the high-frequency hysteresis
TRIGger:HOLDoff Sets or returns the trigger holdoff time
TRIGger:INTRate Sets or returns the internal clock rate
TRIGger:LEVel Sets or returns the trigger level
TRIGger:MODe Sets or returns the trigger mode
TRIGger:PSYNc:CH<x>:DATARate Sets or returns the data rate of the
PatternSync Trigger module speciļ¬ed by
C
H<x>
T
RIGger:PSYNc:CH<x>:DCRAtio
S
ets or returns the DC-to-Clock ratio of the
PatternSync Trigger module speciļ¬ed by
CH<x>
TRIGger:PSYNc:CH<x>:PLENgth Sets or returns the pattern length for the
PatternSync Trigger module speciļ¬ed by
CH<x>
TRIGger:PSYNc:RBIT Sets or returns the relative trigger bit of the
PatternSync Trigger module
TRIGger:PSYNc:SOUrce Sets or returns the pattern sync channel
source
TRIGger:PSYNc:TRIGProbe:DATARate Sets or returns the pattern sync data rate of
the probe connector
TRIGger:PSYNc:TRIGProbe:DCRAtio Sets or returns the DC-to-Clock ratio of the
probe connector
2-40 DSA/CSA/TDS8X00/B Series Programmer Manual
