Commands Listed in Alphabetical Order
Syntax
TRIGger:GATEd
{ON|OFF|NR1}
TRIGger:GATEd?
Related Commands
TRIGger:SOUrce
Arguments
ON enables g ating of the trigger system.
OFF disables gating of the trigger system.
NR1 set to 0 disables gated triggering; any other value enables it.
Examples
TRIGGER:GATED OFF disables the gated triggering feature.
TRIGGER:GATED? might return TRIGGER:GATED 1, indicating that the gated
triggering feature is enabled. If Option GT is not installed, this query always
returns 0 and generates the Execution Error code 2509 with error message Gated
Trigger is not Available.
NOTE. A query always returns a 0 or 1.
TRIGger:HIFreq
This command sets or queries whether the high-frequency triggering function is
enabled. The enhanced triggering control increases the trigger sensitivity of the
trigger circuit by decreasing hysterisis. This allows triggering on higher frequency
signals. This command is equivalent to selectingHighFrequencyTriggeringin
the Enhanced Triggering section of the Trigger Setup dialog box. High Frequency
Triggering is enabled only when the trigger s ource is External Direct.
Group
Trigger
Syntax
TRIGger:HIFreq { ON | OFF | NR1 }
TRIGger:HIFreq?
Related Commands
TRIGger:SOUrce
Arguments
ON enables high-frequency triggering.
OFF disables high-frequency triggering.
NR1 set to 0 disables the high-frequency triggering; any other value enables
the high-frequency triggering.
2-330 DSA/CSA/TDS8X00/B Series Programmer Manual
