Command Groups
The 82A04 modul
eisavailableintwocongurations: standard and with Option
60G. You can nd 82A04 information by clicking the Help button in the Phase Ref
Setup dialog box of instruments running product software versions 2.1 and later.
Command
Description
PHAseref:C
HAR
Initiates a
Phase Reference Characterization
PHAseref:C
H<x>:FREQuency
Sets or retu
rns the Phase Reference
Frequency
PHAseref:CH<x>:RANge? Returns the Phase Reference module
guaranteed frequency range
PHAseref:CH<x> :STAtus? Returns the current Phase R eference
Characte
rization status
PHAsere
f:MODe
Sets or q
ueries the Phase Correction Mode:
OFF, FREerun, TRIGger, or SSCTrigger
PHAseref:SOUrce Sets or r eturns the Phase Reference source:
C1 & C2, C3 & C4, C5 & C6, or C7 & C8
Save and Recall Command Group
You us
e the commands in the Save and Recall Command Group to store and
retrieve internal waveforms and settings. W hen you save a setup, you save all the
settings of the instrument. When you recall a saved setting, the instrument restores
itself to the state that it was in when you originally saved that setting.
Command
Description
DELEte:WAVEform Deletes (one or all) of the stored reference
waveforms from memory
FACtory Resets the instrument to factory default
settings
EXPort
Exports waveform and histogram data to a
le
EXPort:TYPE
Sets or queries the form of the exported
waveform data
IMPort:CUSTommask
Imports and loads the custom mask
RECAll:SETUp
Recalls saved instrument settings
RECAll:WAVEform Recalls a stored w aveform into reference
location
SAVe:SETUp Saves the current instrument settings to a
specied location
SAVe:WAVEform Saves waveform in reference or le
2-32 DSA/CSA/TDS8X00/B Series Programmer Manual
