Commands Listed in Alphabetical Order
from the defaul
t directory. The <filename> can be a Windows long file name. Do
not use wild card characters.
Examples
RECALL:SETU
P FACTOR Y
recalls (and makes current) the instrument setup to its
factory defaults.
RECALL:SETUP "TEK00000.STP" recalls the instrument setup from the file
TEK00000.STP in the default directory and on the default drive.
RECAll:WAVEform (No Query Form)
This command (no query form) recalls a s tored waveform into a reference
location. Sending this command is equivalent to selecting Recall Waveform from
the File Menu, and then selecting a waveform file source and reference destination
in the Recall Waveform dialog box.
Group
Save and Recall
Syntax
RECAll:WAVEform <file path>,REF<x>
Arguments
<filepath> is a quoted string that defines the file name and path. Input the
file path using the form <drive>/<dir>/<filename>. <drive> and one or more
<d
ir>s are optional. If you do not specify them, the instrument will recall the
waveform from the default directory. The <filename> can be a Windows long
file name. Do not use wild card characters.
REF<x> is the location in internal reference memory to which the waveform
is recalled.
Examples
RECALL:WAVEFORM "TEK00000.WFM",REF1 recalls the waveform stored in the
file named TEK00000.WFM in the default directory and on the default drive to
Reference waveform 1.
REF<x>:POSition
This command allows you to set or query the vertical position of the specified
reference waveform. The reference waveform is specified by x, which can be
1 through 8. This is the eq
uivalent to specifying a reference waveform in the
Waveform section of the Vertical Setup dialog box and then entering a value for
Position in the Setup s ection.
Group
Vertical
2-270 DSA/CSA/TDS8X00/B Series Programmer Manual
