Command Groups
Command
Description
MASK:COUNt:SAMPles? Returns the total number of sample points
that have gone into mask counting
MASK:COUNt:STATE Sets or returns the mask counting
MASK:COUN t:TOTal? Returns the sum of all hits in all mask
segments
MASK:COUNt
:WAVeforms?
Returns the
total number of mask hits
MASK:DIS p
lay
Sets or ret
urns whether or not deļ¬ned masks
are displayed on the s creen
MASK:MARgin:PERCent Sets or returns the mask margin in percent
MASK:MARgin:STATE Sets or returns the mask margins state
MASK:MASK<x>
Delete a
ll points in mask<x>
Returns all mask<x>parameters
MASK:MASK<x>:COUNt? Returns number of hits in mask<x>
MASK:MASK<x>:NR_Pt? Returns number of points in mask<x>
MASK:MASK<x>:POInts Returns the points in the speciļ¬ed mask in
waveform coordinates
MASK:MASK<x>:POINTSPcnt Sets or returns the points in mask<x>, in
perc
entage coordinates, with 0,0 upper left
and 100,100 lower right
MASK:SOUrce Sets or returns which waveform and
timebase will be compared against the
mas
k(s) when counting is turned on
MA
SK:STANdard
Se
ts or returns the standard communication
mask
MASK:WFM DB:STAT E Returns whether a waveform database is
used as a source for mask counting
Math Command Group
You u se the commands in the Math Command Group to create and deļ¬ne
math waveforms. You can deļ¬ne and display up to eight math waveforms
simultaneously. You use the available math functions, such as integration,
differentiation, square root, and natural logs, to deļ¬ne your math waveform.
Math expressions can be simple, such as C1, which speciļ¬es that a waveform
should show the signal source of channel 1 with no mathematical computation.
Math expressions can a lso be complex, consisting of 100 plus characters and
comprising many sources, functions, and operators.
Math expressions require at least one source waveform. When the acquisition of a
live waveform stops, so does the acquisition of any math waveforms using that
waveform as a source. When a live waveform update or reference waveform is
altered, math waveforms containing those waveforms as sources are also updated
2-26 DSA/CSA/TDS8X00/B Series Programmer Manual
