Commands Listed in Alphabetical Order
MASK:COUNt:S
TATE
This comma nd sets or queries whether or not mask counting is b eing done.
Sending this command is equivalent to checking or clearing the Enable Mask
Counts check
boxintheSourcesectionoftheMaskSetupdialogbox.
Group
Mask
Syntax
MASK:COUNt:STATE {ON | OFF | <NR1>}
MASK:COUNt:STATE?
Arguments
OFF turns off mask counting. This is the default state.
ON turns on mask counting.
NR1 set to 0 turns off mask counting; any other integer turns on mask counting.
Examples
MASK:COUNT:STATE ON turns on mask counting.
MASK:COUNT:STATE? might return MASK:COUNT:STATE 0, indicating that
mask counting is turned off.
NOTE. A query always returns a 0 or 1.
MASK:COUNt:TOTal? (Query Only)
This query only command returns the sum of all the hits in all the defined masks.
If masks overlap (no standard masks overlap) and a hit occurs in the overlap
region, the total hits will count that hit multiple times. The query returns the
current value, which may be displayed in the Mask readout as Total.
Group
Mask
Syntax
MASK:COUNt:T
OTal?
Returns
NR1
Examples
MASK:COUNT:TOTAL? might return MASK:COUNT:TOTAL 20057, indicating
that the t otal hits in all masks is 20,057.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-201
