Commands Listed in Alphabetical Order
MASK:COUNt:W
AVeforms? (Query Only)
This query only command returns the number o f waveforms that have contributed
to mask counting. This value may be displayed in the Mask readout as Waveforms.
Group
Mask
Syntax
MASK:COUNt:WAVeforms?
Returns
NR1
Examples
MASK:COUNT:WAVEFORMS? might return MASK:COUNT: WAVEFORMS 6568,
indicating that the total number of waveforms contributed to mask counting
is 6,568.
MASK:DISplay
This command sets or queries whether or not definedmasksaredisplayedonthe
screen. This is useful for temporarily turning off user-defined masks without
deleting them. This is equivalent to checking or clearing the Display Mask control
in the Options section of the Mask Setup dialog box.
Group
Mask
Syntax
MASK:DISplay {OFF | ON | <NR1>}
MASK:DISplay
Arguments
OFF removes the masks from the display; this does not turn mask counting
off. This is the default value.
ON displays the masks. Turning mask counting on turns this on. Selecting
any standard mask turns this on. MASK:MASK<x>:POINTSPCNT or
MASK:MASK<x>:POINTS turns this on.
NR1 set to 0 turns off the mask display; any other integer turns on the m ask
display.
Examples
MASK:DISPLAY ON sets the display to show the defined masks.
MASK:DISPLAY? might return 1, indicating that the display shows masks.
2-202 DSA/CSA/TDS8X00/B Series Programmer Manual
