Command Groups
Command
Description
HARDCopy Sends a screen copy to the selected port or
returns the selected port and file path
HARDCopy:FILEName Sets or returns the hard copy fi le path
HARDCopy:FORMat Selects the file format when sending
a hardcopy t
oafile using the
HARDCopy:FILEName command
HARDCopy:INKSaver Sets the Ink-saver mode on or off. Ink-saver
mode can conserve ink and improve print
quality wh
en printing images of waveform
displays
Histogra
m Command Group
Histogram commands let you select the type of histogram, what part of the
waveform should go into the histogram, and histogram statistics. You can use
comman
ds from this group to do the following:
Select any channel, math, or reference waveform and create a histogra m of
vertic
al or horizontal values for it.
Adjust the limits o f the box that define the area on the waveform from which
the hi
stogram data is obtained. The h istogram box can be set using source
waveform coordinates or percentage-of-display coordinates.
Crea
te a linear or logarithmic plot of histogram data and set plot size and color.
Clear histogram count and restart.
Turn the display of the histogram on or off.
Enable or disable histogram calculations.
Get histogram statistics, such as total hits, mean value, peak-to-peak value,
and standard deviation.
Get all the histogram parameters.
NOTE. You can also export a histogram to a file of comma-separated values. See
the EXPort command for more information.
Command
Description
HIStogram?
Return all histogram parameters
HIStogram:BOX Sets or returns the left, top, right, and bottom
positions of the histogram box, in source
waveform coordinates
2-20 DSA/CSA/TDS8X00/B Series Programmer Manual
