Command Groups
to reļ¬ect the ch
anges. Also, sources must e xist, but do not need to be displayed to
be used in and to update math waveforms.
Command
Description
MATH<x>?
Returns math<x> settings
MATH<x>:DEFine
Sets or returns the math<x> de ļ¬nition
MATH<x>:FILTer:MODe Sets or returns the ļ¬lter mode for the
math<x> w aveform
MATH<x>:FILTer:RISetime Sets or returns the risetime (bandwidth) of
the math ļ¬lter function
MATH<x>:NUMavg
Sets or returns the number of waveforms
to average for a math waveform for the
math<x> w aveform
MATH<x>:POSition Sets or returns the math<x> vertical position
MATH<x>:SCAle Sets or returns the math<x> vertical scale
(per div)
MATH<x>:UNIts?
Returns m ath units
MATH<x>:WFMLabel
Sets or returns the label associated with the
math<x> w aveform
Measurement Command Group
You use the commands in the Measurement Command Group to control the
automated measurement system. Up to eight automated measurements ca n be
displayed on the screen. In the commands, these eight meas urement slots are
named MEAS<x>, where <x> can be 1 through 8. You use the commands to
do the following:
DSA/CSA/TDS8X00/B Series Programmer Manual 2-27
