Commands Listed in Alphabetical Order
MATH<x>:FILT
er:MODe
This command sets or queries the filter mode for the math waveform specified by
x, which can be 1 through 8.
Group
Math
Syntax
MATH<x>:FILTer:MODe {CENTered | SHIFted}
MATH<x>:FILTer:MODe?
Related Commands
MATH<x>:DEFine, MATH<x>:FILTer:RISetime
Arguments
CENTered invokes a centered filter mode that is noncausal and uses an
average that is centered on each point. This is the default.
SHIFted invokes a shifted filter mode that is causal and forms the average for
each point based only on preceding points.
Examples
MATH2:FILTER:MODE CENTERED sets the filter mode to centered for the
specified math waveform.
MATH5:FILTER:MODE? might return MATH5:FILTER :MODE SHIFTED,
indicating that the shifted filter mode is applied to t he Math 5 waveform.
MATH<x>:FILTer:RISetime
This command sets or queries the risetime (bandwidth) of the math filter function.
Group
Math
Syntax
MATH<x>:FILTer:RISetime <NR3>
MATH<x>:FILTer:RISetime?
Related Commands
MATH<x>:DEFine, MATH<x>:FILTer:MODe
Arguments
NR3 is the value of the ri
setime.
Examples
MATH2:FILTER:RISETIME 1.0E–12 sets the risetime of the Math 2 risetime
filter to 1 ps.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-217
