Commands Listed in Alphabetical Order
Arguments
CH<x> selects a
channel waveform to be compared against the specified mask.
The range for x is 1 through 8.
MATH<x> selec
ts a m ath waveform to be compared against the specified mask.
The range for x is 1 through 8.
REF<x> sele
cts a reference w aveform to be compared against the specified
mask. The range for x is 1 through 8.
MAIn (optio
nal) selects Main as the timebase for the specified waveform to be
compared against the mask. This is the default timebase.
MAG1 (opti
onal) selects MAG1 as the timebase for the specified waveform to
be compared against the mask.
MAG2 (opt
ional) selects MAG2 as the timebase for the specified waveform to
be compared against the mask.
Examples
MASK:S
OURCE C H1
enables CH1 to be compared against the mask. Since a
timebaseisnotspecified, the default, Main, is used.
MASK:
SOURCE?
might return MASK:SOURCE CH1,MAIN, indicating that the
Channel 1 waveform will be compared against the mask using the Main timebase.
MASK:STANdard
This command selects a set of predefined mask polygons (hereafter referred to
as a “mask”) to be used for mask testing in accordance with the communications
standard specified by the command argument. The query form of this command
re
turns the current mask. Note the following usage rules:
2-208 DSA/CSA/TDS8X00/B Series Programmer Manual
