Commands Listed in Alphabetical Order
Setting the MAS
K:STANdard sets the HORizontal:BITS:STANdard to the
same argument, thereby setting the horizontal bit rate to the bit rate associated
with the selected standard.
Do not use the USERMask to select a user-defined mask; rather use the
MASK:MASK<X>:POInts and/or the MASK:
MASK<X>:POINTSPcnt
commands to define the mask. This action c oerces the MASK:STANdard
and HORizontal:BITS:STANdard settings to USERMask. (The USERMask
setting cannot be selected directly with the MASK:STANdard command,
but MASK:STANdard queries will return USERMask when user-defined
masks are selected.)
When you use user-defined masks, you should set the horizontal bit rate
explicitly with the HORizontal:BITS:BITRate command.
You can use the MASK:MASK<X> commands to access the current masks,
whether predefined or user defined, and their associated counters.
If you specify user-defined masks, note that selecting one of the predefined
mask standards will overwrite your user-defined masks. If your test is related
to one of the predefined mask standards, you might want to first select the
related predefined standard, and then only modify the masks and/or bit rate
as required.
Specifying a mask communication standard other than User or None coerces
the MASK:AUTOSet:HILow:METHod to MEAN.
Changing the MASK:AUTOSet:HILow:METHod from MEAN to MODe
coerces the mask communication standard to USER.
Selecting NONe will delete all c urrently defined masks.
If MASK:COUNt:STATE is ON, then mask counting starts.
Custom mask definitions must be imported before it can be used.
Group
Mask
Syntax
MASK:STANdard { NONe | CUSTom | ATARXG1 | ATARXG2 | ATARXG3
| ATATX G1 | ATATXG2 | ATATXG3 | ENET40GB_LR4 | ENET40GB_SR4
| ENET1 250 | ENET25 00 | ENET3125 | ENET9953 | ENET10313 |
ENET10GB_LRM | ENET100 B_BX10 | ENET100GB_ER4 | ENET100GB_LR4
| ENET1 00GB_SR10 | ENET100B_LX10 | ENET1000B_KX | ENET10313
| ENET1 1096 | ENET41250 | FC133 | FC133E | FC266 | FC266E
| FC531 | FC531E | FC1063 | FC1063E | FC2125 | FC2125E_ABR
| FC212 5E_ABT | FC2125E_AGR | FC2125E_AGT | FC4250E_ABR
| FC425 0E_ABT | FC4250E_AGR | FC4250E_AGT | FC8500E_ABR
| FC850 0E_ABT | FC8500E_AGR| FC8500E_AGT | FC8500D |
FC8500FINAL | FC4250 | FC10519 | FC11317 | FC14025_MMR6_1 |
FC14025_SMR6_1 | FEC2666 | FEC10664 | FEC10709 | FEC42657
| FEC43 018 | INF250 0 | INFIE25 | INFIniband | OC1 | OC3
DSA/CSA/TDS8X00/B Series Programmer Manual 2-209
