Commands Listed in Alphabetical Order
Syntax
TRIGger:MODe {
NORMal | AUTO}
TRIGger:MODe?
Related Commands
TRIGger:SOUrce
Arguments
NORMal sets the trigger mode to Normal (see Description above).
AUTO sets the
trigger mode to Auto (see Description above).
Examples
TRIGGER:MODE NORMAL sets the trigger mode to Normal.
TRIGGER:MODE? might return TR IGGER:MODE AUTO, indicating that the
triggering mode is set to autotrigger.
TRIGger:PSYNc:CH<x>:DATARate
This command sets or queries the data rate (<nr3>) of the PatternSync Trigger
module for the channel speciļ¬ed (CH<x>), which can be 1 through 8. The channel
speciļ¬ed must be from a PatternSync Trigger m odule. The data rate must be in
the range available for the channel/module speciļ¬ed.
The query form returns the data rate for the PatternSync Trigger module speciļ¬ed
by the channel.
If you attempt to modify this parameter while the AUTOSync:DATARate is
ON, you will receive Execution Error code 2539 with an error message "Pattern
Sync Parameter is not settable". (See Messages for general information o n
programming interface messages.)
Group
Trigger
Syntax
TRIGger:PSYNc:CH<x>:DATAR ate <nr3>
TRIGger:PSYNc:CH<x>:DATAR ate?
Examples
TRIGGER:PSYNC:CH1:DATARAT E 12.6E9 deļ¬nes the data rate for channel 1
as 12.6 Gb/s.
TRIGGER:PSYNC:CH1:DATARAT E? might return
TRIGGER:PSYNC:CH1:DATARAT E 12.60000000000E+9, indicating the current
bit rate is 12.6 Gb/s for channel 1.
2-334 DSA/CSA/TDS8X00/B Series Programmer Manual
