Command Groups
Set deskew valu
es to compensate for delay between channe l s.
Set the units for channel waveforms. If you set this value to Auto, the
instrument au
tomatically selects the units. If you set this value to any setting
other than Auto (Volt, Amp, or Watt), the instrument will apply these units to
the vertical axis.
Set the external attenuation factor (as a multiplier or as a d B value) on an
acquisition channel waveform to a value matching the amount of attenuation
applied externally, before the signal enters the sampling head or probe tip
input.
Set the wavelength to match the wavelength of the optical signal you are using.
Set the type of filtering, if any, you want performed on the selected optical
channel.
Specify bandwidth for use on the selected optical channel.
Comman
d
Description
AUTOSe
t:VERTical
Sets or
returns whether the vertical Autoset
options are included when Autoset executes
CH<x>?
Retur
ns the vertical parameters
CH<x>:ERCAL?
Retur
ns whether calibrated extinction ratio
is available for the optical module for the
specified channel
CH<x>:BANdwidth:LIST? Returns the bandwidths available for the
spec
ified channel
CH<
x>:BANdwidth:VALue
Set
s or returns the bandwidth for the
specified channel
CH<x>:DELay Sets or returns the delay time for the
specified channel
CH<x>:DESkew Sets or returns the deskew time
CH<x>:EXTAtten:MODe Sets or returns the external attenuation mode
CH<x>:EXTAtten:VALue Sets or returns the external attenuation
factor (as a multiple)
CH<x>:FILTer:LIST? Returns filter list for the specified channel
CH<x>:FILTer:VALue Sets the hardware filter for the specified
channel
CH<x>:OFFSet Sets or returns the channel offset
CH<x>:POSition Sets or r eturns the channel vertical position
CH<x>:SCAle Sets or returns the channel vertical scale
(per div)
CH<x>:UNIts Sets or returns the channel vertical units
CH<x>:WFMLabel Sets or returns the label associated with the
specified channel waveform
2-42 DSA/CSA/TDS8X00/B Series Programmer Manual
