Commands Listed in Alphabetical Order
Arguments
PSYNc sets the t
rigger source to Pattern Sync (see Description above).
EXTDirect sets the trigger source to External Direct (see Description above).
EXTPrescaler sets the trigger source to External Prescaler (see Description
above).
INTClk sets the trigger source to Internal Clock (see Description above).
CLKRECovery sets the trigger source to Clock Recovery (see Description
above).
Examples
TRIGGER:SOURCE EXTDIRECT sets the trigger source to External Direct.
TRIGGER:SOURCE? might return TRIGGER:SOURCE INTCLK, indicating that the
trigger source is currently set to the internal clock.
TRIGger:STATE? (Query Only)
This query returns the status of the trigger system.
Group
Trigger
Syntax
TRIGger:STATE?
Related Commands
TRIGger:MODe
Returns
AUTOING indicates that the trigger system is active and is forcing auto triggers
in absence of valid triggers.
TRIGGERED indicates that the trigger system is active, and the instrument is
triggered.
NOTTRIGGERED indicates that the trigger system is active, and the instrument is
not triggered.
STOPPED indicates that the acquisition is disabled s o the state of trigger system is
ignored.
Examples
TRIGGER:STATE? might return TRIGGER:STATE TRIGGERED, indicating that
the instrument is triggered.
2-342 DSA/CSA/TDS8X00/B Series Programmer Manual
