Tektronix DSA8200 Series User Manual

Appendix C: Factory Default Setup Values
Command Default Values
DISplay:COLor:FOREground 15 (white)
DISplay:COLor:HIStogram 2 (blue)
DISplay:COLor:MASK 4 (fuchsia)
DISplay:CURSReadout 0(OFF)
DISplay:GRAticule:STYLE
FULL
DISplay:HISTReadout 0(OFF)
DISplay:INTERPolat SINX
DISplay:MASKReadout 0(OFF)
DISplay:MEASBar 0(OFF)
DISplay:MEASReadout 0(OFF)
DISplay:PERSistence
2.000E
+002
DISplay:SHOWVector 0(OFF)
DISplay:STYle NORMAL
DISplay:WFMReadout 0(OFF)
Histogram Default Values
The following table lists the Histogram factory default setup values.
Command Default Values
HIStogram:BOX 0(OFF)
HIStogram:BOXPcnt
3.000E+001
2.510E+001
7.000E+001
7.520E+001
HIStogram:COLOr 2 (blue)
HIStogram:DISplay 0(OFF)
HIStogram:ENABle 0(OFF)
HIStogram:MODe HORIZONTAL
HIStogram:SIZe
2
HIStogram:SOUrce CH1,MAIN
HIStogram:TYPE
LINEAR
HIStogram:WFMDB:STATE 0(OFF)
Horizontal Default Values
The following table lists the Horizontal factory default setup values.
Command Default Values
HORizontal:BITS:BITRate
2.488E+009
HORizontal:BITS:STANdard NONE
HORizontal:DISTance:DIELectric
1
C-2 DSA/CSA/TDS8X00/B Series Programmer Manual
