Commands Listed in Alphabetical Order
Examples
DISPLAY:GRATI
CULE:HDIVS?
might return DISPLAY:GRATICULE:HDIVS 10,
indicating that the graticule display is 10 horizontal divisions wide.
DISplay:GRAticule:STYLE
This command selects the style of graticule that is displayed. Sending the
command is equivalent to setting Style in the Graticule section of the Display
Setup dialog box. The following are the available graticule styles:
Full (default)
Cross Hair
Grid
Frame
Group
Display Control
Syntax
DISplay:GRAticule:STYLE { FULl | C
ROSSHair | GRId | FRAme }
DISplay:GRAticule:STYLE?
Arguments
FULl specifies a frame, a grid, and cross hairs.
CROSSHair specifies a frame and cross hairs.
GRId specifies a frame and a grid.
FRAme specifies just a frame.
Examples
DISPLAY:GRATICULE:STYLE GRID sets the graticule style t
o display a frame
and a grid.
DISPLAY:GRATICULE:STYLE? might return DISP LAY:GRATI
CULE:STYLE
FULL
when all graticule elements (grid, frame, and cross hairs) are displayed.
DISplay:GRAticule:VDIVS? (Query Only)
This query only command returns the number of vertical divisions in the graticule.
Group
Display Control
Syntax
DISplay:GRAticule:VDIVS?
DSA/CSA/TDS8X00/B Series Programmer Manual 2-125
