Commands Listed in Alphabetical Order
HIStogram:EN
ABle
This command sets or queries whether the histogram calculations are enabled.
This is equivalent to selecting Enable Histogram in the Source section of the
Histogram Se
tup dialog box. Sending this command will cause the histogram
statistics to be displayed (but not the histogram). Use the H IStogram:DISplay
command to control whether the histogram is d isplayed on screen.
Group
Histogram
Syntax
HIStogram:ENABle { ON | OFF | NR1 }
HIStogram:ENABle?
Arguments
ON enables histogram calculations.
OFF disables histogram calculations.
NR1 set to 0 disables the histogram calculations; any other value enables
histogram calculations.
Examples
HISTOGRAM:ENABLE ON enables histogram calculations.
HISTOGRAM:ENABLE? might return HISTOG RAM:ENABLE 0, indicating that
the histogram calculations are disabled.
NOTE. A query always returns a 0 or 1.
HIStogram:MODe
Selects the type of histogram to create. This is equivalent to selecting either
Vertical or Horizontal in the Source section of the Histogram Setup dialog box.
Group
Histogram
Syntax
HIStogram:MODe {HORizontal | VERTical}
HIStogram:MODe?
Arguments
HORizontal displays a horizontally positioned histogram that shows time
distribution.
VERTical displays a vertically positioned histogram that shows a voltage
distribution (or other vertical distribution, such as amperes).
2-146 DSA/CSA/TDS8X00/B Series Programmer Manual
