Commands Listed in Alphabetical Order
PCIEXPRESS_Rc
v
selects the 2.5 Gb/s bit rate and mask, in accordance with
the PCI Express Receiver, 2.5 G b/s standard.
PCIEXPRESS50_Rcv selects the 5 Gb/s bit rate and mask, in accordanc e with
the PCI Express Receiver, 5 Gb/s standard.
RIO_SERIAL1G selects the 1.25 Gb/s bit rate and mask, in accordance with
the Rapid IO Serial, 1.25 Gb/s standard.
RIO_SERIAL2G selects the 2.5 Gb/s bit rate and mask, in accordance with the
Rapid IO Serial, 2.5 Gb/s standard.
RIO_SERIAL3G selects the 3.25 Gb/s bit rate and mask, in accordance with
the Rapid IO Serial, 3.25 Gb/s standard.
SAS3_0_XR selects the 3 Gb/s bit rate and mask.
SAS3_0_XR_AASJ selects the 3 Gb/s applied sinusoidal jitter bit rate and
mask.
SAS3_0_SATA selects the 3 Gb/s bit rate and mask.
USERMask selects user-deļ¬ned masks for testing (see Description, above).
XFI9950_TAA selects the 9.95 Gb/s bit rate and mask.
XFI9950_RAD selects the 9.95 Gb/s bit rate and mask.
XFI9950_THB selects the 9.95 Gb/s bit rate and mask.
XFI9950_RHC selects the 9.95 Gb/s bit rate and mask.
XFI9950_TMBP selects the 9.95 Gb/s bit rate and mask.
XFI9950_RMCP selects the 9.95 Gb/s bit rate and mask.
XAUIFar selects the 3.1250 Gb/s far-end normalized bit rate and mask, in
accordance with the IEEE 802.3ae-2002 standard.
XAUIRFar selects the 3.1250 Gb/s far-end relative bit rate and mask, in
accordance with the IEEE 802.3ae-2002 standard.
XAUINear selects the 3.1250 Gb/s near-end normalized bit rate and mask, in
accordance with the IEEE 802.3ae-2002 standard.
XAUIRNear selects the 3.1250 Gb/s near-end relative bit rate and mask, in
accordance with the IEEE 802.3ae-2002 standard.
HORizontal:DISTance:DIELectric
This command sets or queries the dielectric constant. This is equivalent to setting
the Dielectric constant in the Distance section of the Horizontal Setup dialog box.
Group
Horizontal
DSA/CSA/TDS8X00/B Series Programmer Manual 2-159
