Commands Listed in Alphabetical Order
Arguments
NR3 (first) is th
e left position of the histogram box in percentage coordinates.
The default value is 30.
NR3 (second) i
s the top position of the histogram box in percentage
coordinates. The default value is 25.
NR3 (third)
is the right position of the histogram box in percentage coordinates.
The default value is 70.
NR3 (forth)
is the bottom position of the histogram box in percentage
coordinates. The default value is 75.
Examples
HISTOGRA
M:BOXPCNT 35,21,72,76
defines the coordinates of a histogram
box in percentage coordinates.
HISTOGR
AM:BOXPCNT?
might return H ISTOGRAM:BOXPCN T 30.0000000000,
25.0000000000, 70.0000000000,75.000 0000000
.
HIStogram:COLOr
This command sets or queries the color of the histogram data and its boundary
area. (This command is the same as the DISplay:COLor:HIStogram command.)
This is equivalent to setting Color in the Display Options section of the Histogram
Setu
p dialog box. The available colors are listed in the following table.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-143
