Tektronix DSA8200 Series User Manual

Appendix C: Factory Default Setup Values
Command Default Values
HORizontal:DISTance:PVELocity
2.998E+10
HORizontal:EXT10MHZref:FREQ
1.000E+007
HORizontal:FRAMescan:AUTOPosition 0(OFF)
HORizontal:FRAMescan:SCANBits
64
HORizontal:FRAMescan:STARTBit
4.600E+001
HORizontal:FRAMescan:STATE 0(OFF)
HORizontal:MAGnify<x>:POSition
1.875E-0
08
HORizontal:MAGnify<x>:RECordlength
500
HORizontal:MAGnify<x>:REFPoint
5.000E-
001
HORizontal:MAGnify<x>:SCAle
5.000E-
001
HORizontal:MAGnify<x>:VIEW 0(OFF)
HORizontal:MAIn:POSition
2.050
E-008
HORizontal:MAIn:RECordlength
500
HORizontal:MAIn:REFPoint
50
HORizontal:MAIn:SCAle
5.00
0E-10
HORizontal:TBMode SHORTTERM
HORizontal:UNIts S
Mask Default Values
The following table lists the Mask factory default setup values.
Command Default Values
MASK:AUTOSet:MODe
MANUAL
MASK:COLOr 4 (fuchsia)
MASK:COUNt:STATE 0(OFF)
MASK:DISplay 0(OFF)
MASK:MARgin:PERCent
5.000E+000
MASK:MARgin:STATE 0(OFF)
MASK:SOUrce CH 1,M A IN
MASK:STANdard NONE
MASK:WFMD B:STATE 0(OFF)
Math Default Values
The following table lists the Math factory default setup values.
Command Default Values
MATH<x>:DEFine ""
MATH<x>:FILTer:MODe CENTERED
MATH<x>:NUMavg 2
MATH<x>:POSition
0.00E+000
DSA/CSA/TDS8X00/B Series Programmer Manual C-3
