Commands Listed in Alphabetical Order
Syntax
HORizontal:FR
AMescan:STATE { ON | OFF | NR1 }
HORizontal:FRAMescan:STAT E?
Arguments
ON enables the FrameScan mode.
OFF disables the FrameScan mode.
NR1 set to 0 disables the FrameScan mode; any other value enables the
FrameScan mode.
Examples
HORIZONTAL:FRAMESCAN:STAT E ON enables the FameScan mode.
HORIZONTAL:FRAMESCAN:STAT E? might return
HORIZONTAL:FRAMESCAN:STAT E 0, indicating that the FrameScan mode is
currently disabled.
NOTE. A query always returns a 0 or 1.
HORizontal:MAGnify<x>? (Query Only)
This query only command returns the timebase settings for the specified Mag
timebase. The Mag timebase is specified by x, which can be 1 or 2.
Group
Horizontal
Syntax
HORizontal:MAGnify<x>?
Examples
HORIZONTAL:MAG1? might return HORIZONTAL:MAGNIFY1:SCALE
1.05200000000E–009; POSITION 64.0380000000E–009;
RESOLUTION 5.26000000000E–012; RECORDLENGTH 200 0;REFPOINT
0.00000000000; VIEW 1; TOLPOINT 74.5580000000E–009; TOFPOINT
64.0380000000E–009
.
HORizontal:MAGnify<x>:POSition
This command sets or queries the horizontal position for the specified Mag
timebase. The Mag timebase is speci fied by x, which can be 1 or 2. Sending this
command is equivalent to selecting a Mag timebase and entering a value in the
Position control in the Timebase section of the Horizontal Setup dialog box or
adjusting the front-panel Horizontal position control.
2-164 DSA/CSA/TDS8X00/B Series Programmer Manual
