Commands Listed in Alphabetical Order
Arguments
ON turns on the v
iew of the specified Mag timebase.
OFF turns off the view of the specified Mag timebase.
NR1 set to 0 disables the specified Mag timebase view; any other integer
enables the specified Mag timebase view.
Examples
HORIZONTAL:MAG2:VIEW ON displays the Mag2 timebase.
HORIZONTAL:MAG1:VIEW? might return HORIZONTAL:MAGNIFY1:VIEW 0,
indicating that the display of the Mag1 timebase is disabled.
NOTE. A query always returns a 0 or 1.
HORizontal:MAIn? (Query Only)
This query only command returns the settings of the main time base.
Group
Horizontal
Syntax
HORizontal:MAIn?
Examples
HOR
IZONTAL:MAIN?
might return HORIZONTAL:MAIN:SCA LE
2.00000000000E–009; POSITION 20.3000000000E–009;
RESOLUTION 5.00000000000E–012;RECORDLENGT H 4000; REFP OINT
0.00000000000; TOLPOINT 40.3000000000E–009; TOFPOINT
20.3000000000E–009
.
HORizontal:MAIn:POSition
T
his command sets or queries the horizontal position for the Main timebase.
Sending this command is equivalent to selecting MainTB and entering a value in
the Position control in the Timebase section of the Horizontal Setup dialog box or
adjusting the front-panel Horizontal position control.
2-172 DSA/CSA/TDS8X00/B Series Programmer Manual
