Tektronix DSA8200 Series User Manual

Commands Listed in Alphabetical Order
Arguments
MEAN sets Mask A
utoset to use the mean of the High level (topline) and Low
level (baseline) within a fixed eye aperture (center 20% of the eye) to align the
input signal to the NRZ mask. Mean is the default state and is automatically
selected whenever a mask communication standard other than User or none
is specified.
MODe sets Mask Autoset to use the mode of the High level (topline) and
Low level (baseline) across one unit interval of the eye diagram to align the
input signal to the NRZ mask. Setting the method to Mode coerces the mask
communica
tion standard to User.
Examples
MASK:AUTOSET:HILOW:METHOD MODE sets the Mask Autoset high/low method
to Mode.
MASK:AUTOSET:HILOW:METHOD ? might return MEAN, indicating that the current
Mask Autoset High/Low method setting is Mean.
MASK:AUTOSet:MODe
This command sets or queries whether or not a mask autoset will automatically be
done after a standard mask is selected. This is equivalent to selecting Automatic
or Manual in the Autoset section of the Mask Setup dialog box.
Group
Mask
Syntax
MASK:AUTOSet:MODe {AUTO | MANual}
MASK:AUTOSet:MODe?
Arguments
AUTO sets the instrument to automatically run the mask autoset when a
standard mask (or a user-defined mask that is derived from a standard mask)
is selected from the Comm Standard section of the Mask Setup dialog box.
Autoset will not run continuously; it will run once when a standard is selected.
MANual sets the mask autoset algorithm for a standard mask to run only if the
user presses the autoset button or sends the AUTOSet
EXECute command. If
a standard mask (or a user-defined mask that is derived from a standard mask)
is not currently selected, the mask autoset algorithm will not run, and the
normal autoset will run when the user presses the Autoset button. Manual is
the default value.
Examples
MASK:AUTOSET:MODE AUTO sets the instrument to automatically run autoset
when a standard mask is selected from the Comm Standard section of the Mask
Setup dialog box.
2-198 DSA/CSA/TDS8X00/B Series Programmer Manual
