Commands Listed in Alphabetical Order
Arguments
NR3 is the exter
nal 10 MHz frequency setting. The range for this argument is
1.0E7 ±0.1% (9.99 MHz through 10.01 MHz). The resolution is 0.1 Hz. The
default is 1 0 MHz.
Examples
HORIZONTAL:EXT10MHZREF:FRE Q 9.999E6 sets the horizontal external
10 MHz frequency to 9.999 MHz.
HORIZONTAL:EXT10MHZREF:FRE Q? might return
HORIZONTAL:EXT10MHZREF:FRE Q 10.0000000000E+006, indicating that the
horizontal external 10 MHz frequency is set to the default value.
HORizontal:FRAMescan:AUTOPosition
This command sets or queries whether or not Auto Position is enabled when in
FrameScan mode. When Auto Position is enabled, the FrameScan mode starts
scanning with an initial horizontal position specified by the start bit set by the
HORizontal:FRAMescan:STARTBit command. Otherwise, scanning starts at the
current horizontal bit location. Sending this command is equivalent to checking
the Auto Position box in the FrameScan section of the Horizontal Setup dialog
box.
Group
Horizontal
Syntax
HORizontal:FRAMescan:AUTOP osition { ON | OFF | NR1 }
HORizontal:FRAMescan:AUTOP osition?
Related Commands
HORizontal:FRAMescan:STARTBit
Arguments
ON enables Auto Position mode, which starts the scan at the start bit specified
by the HORizontal:FRAMescan:STARTBit command.
OFF disables Auto Position. Scanning will start at the current horizontal bit
location.
NR1 set to 0 disables Auto Position; any other value enables Auto Position.
Examples
HORIZONTAL:FRAMESCAN:AUTOP OSITION 1 enables Auto Position.
HORIZONTAL:FRAMESCAN:AUTOP OSITION? might return
HORIZONTAL:FRAMESCAN:AUTOP OSITION 0, indicating that Auto
Position is disabled.
NOTE. A query always returns a 0 or 1.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-161
