Commands Listed in Alphabetical Order
CURSor:CURSo
r<x>:SOUrce
This command sets or queries which waveform is a ssociated with the specified
cursor. The cursor is specified by x, which can be 1 or 2. This command can
optionally s
et the target timebase. This is equivalent to selecting a waveform
(and timebase) in the Source control for the Cursor 1 or Cursor 2 section of the
Cursor Setup dialog box. If you do not set the timebase, the default is Main for
both cursors.
Group
Cursor
Syntax
CURSor:CURSor<x>:SOUrce {CH<x> | MATH<x> | REF<x>}[,{MAIn |
MAG1 | MAG2}]
CURSor:CURSor<x>:SOUrce?
Arguments
CH<x> selects a channel waveform as the source for the specified cursor.
The range for x is 1 through 8.
MATH<x> selects a math waveform as the source for the specified cursor.
The range for x is 1 through 8.
REF<x> selects a reference waveform as the source for the specified cursor.
The range for x is 1 through 8.
MAIn (optional) se lects Main as the timebase for the specified cursor display.
MAG1 (optional) selects MAG1 as the timebase for the specified cursor display.
MAG2 (optional) selects MAG2 as the timebase for the specified cursor display.
Examples
CURSOR:CURSOR2:SOURCE CH8,MAG1 associates Cursor 2 w ith the channel 8
waveform and the MAG1 timebase.
CURSOR:CURSOR1:SOURCE? might return CURSOR:CURSOR1:SO URCE
REF2,MAIN
, indicating that Cursor 1 is associat ed with the REF2 waveform
and t
he Ma in timebase.
CURSor:FUNCtion
This command sets or queries cursor type. Cursors are attached to the selected
waveform. Sending this command is equivalent to setting Function in the Cursor
Setup dialog box.
Group
Cursor
DSA/CSA/TDS8X00/B Series Programmer Manual 2-101
