Tektronix DSA8200 Series User Manual

Commands Listed in Alphabetical Order
Syntax
CURSor:FUNCti
on { HBArs | OFF | VBArs | WAVEforms }
CURSor:FUNCtion?
Related Commands
SELect:CONTROl
Arguments
HBArs enables horizontal bar cursors, which provide traditional vertical unit
readouts for Cursor 1 (bar1), Cursor 2 (bar2), and the D between them.
OFF removes the cursors from the display.
VBArs enables vertical bar cursors, which provide traditional horizontal unit
readouts for Cursor 1 (bar1), Cursor 2 (bar2), the D between them, and 1/Dt
(frequency when the horizontal unit is time).
WAVEforms enables the waveform cursors, which provide both horizontal
unit readouts and vertical unit readouts for Cursor 1 a nd Cursor 2, which are
constrained to valid data points of the selecte d wavef orm.
Examples
CURSOR:FUNCTION VBARS enables the vertical bar type cursors.
CURSOR:FUNCTION? might return CURSOR:FUNCTION HBARS, indicating that
the horizontal bar cursors are enabled.
CURSor:HBArs? (Query Only)
This query only command returns the current settings for the horizontal bar
cursors.
Group
Cursor
Syntax
CURSor:HBArs?
Examples
CURSOR:HBARS? might return CURSOR:HBARS: DELTA
-4.01084010840E-003; POSITION1 2.01897018970E-003;
POSITION2 -1.99186991870E-003
.
CURSor:HBArs:DELTa? (Query Only)
This query only command returns the difference between the two horizontal bar
cursors.
Group
Cursor
2-102 DSA/CSA/TDS8X00/B Series Programmer Manual
