High Voltage SourceMeter Instrument User's Manual Section 1:
2470-900-01 Rev. B / August 2019 1-3
Organization of manual sections
This manual is organized into the following sections:
• Front-panel overview (on page 2-1): Describes the basics of using the front-panel interface.
• Using a remote interface (on page 3-1): Describes the basics of remote communications and
using the instrument web interface.
• Application examples (see below): Provides detailed examples of how to use the 2470 in some
typical situations.
• Troubleshooting FAQs (on page 7-1): Provides answers to frequently asked questions to help you
troubleshoot common problems encountered with the 2470.
• Next steps (on page 8-1): Provides information about additional resources that can help you use
the 2470.
The PDF version of this manual contains bookmarks for each section. The manual sections are also
listed in the Table of Contents at the beginning of this manual.
For more information about bookmarks, see Adobe
®
Acrobat
®
or Reader
®
help.
Applications
This manual provides application examples that show you how to perform tests from the front panel
and over a remote interface. These applications are presented after the summary information about
the 2470. The applications include:
• Making basic front-panel measurements (on page 4-1): Demonstrates the basic measurement
functionality using a single 2470 and a two-terminal device under test (DUT).
• Leakage current and insulation resistance (on page 5-1): Demonstrates how to use a 2470 to
make high resistance measurements on two-terminal DUTs.
• Measure I-V characteristics of FETs (on page 6-1): Demonstrates how to use one or two 2470s to
verify and characterize field-effect transistors (FETs).
