High Voltage SourceMeter Instrument User's Manual Section 3:
2470-900-01 Rev. B / August 2019 3-11
9. In the Virtual Instrument Name box, enter a name that you want to use to refer to the instrument.
10. Select Finish.
11. Select Cancel to close the Wizard.
12. Save the configuration. From the Keithley Configuration Panel, select File > Save.
Verify the instrument through the Keithley Communicator:
1. Set the instrument to use the SCPI command set. Refer to How do I change the command set?
(on page 7-3) for instruction.
2. Click Start > Keithley Instruments > Keithley Communicator.
3. Select File > Open Instrument to open the instrument you just named.
Figure 17: Keithley Communicator Open an Instrument
4. Click OK.
5. Send a command to the instrument and see if it responds.
If you have a full version of NI-VISA on your system, you can run NI-MAX or the VISA Interactive
Control utility. See the National Instruments documentation for information.
