Analyze Waveform Data
Using Reference Waveforms
Create a reference waveform to store a waveform. For example, you might do this to set up a standard against which to compare
other waveforms. To use the reference w avef orms:
NOTE. 10 M reference waveforms are vo latile and not saved when the oscilloscope power is turned off. To keep th ese waveforms,
save the m to externa l storage.
1. Push Ref R . This brings up the lower-bezel
reference me nu.
2. Use the resulting lower-bezel menu select ions
to display or select a reference waveform.
(R1) |
(On)
3-May-07
(R2) |
(Off)
(R3) |
(Off)
(R4) |
(Off)
222 MSO4000 and DPO4000 Series Oscilloscopes User Manual
To Next Page
