Tektronix MSO4104 User Manual

Using Application M od ules
The DPO4VID Extended Video Mo dule adds triggering on a variety of standard HDTV signals, as well as on custom
(non-standard) bilevel and trilevel video signals with 3 to 4,0 00 lines.
The DPO4AUDIO Audio Serial Triggering and Analysis Modu le add s triggering on I
2
S, Left Justified (LJ), Right Justified
(RJ), and TDM buses.
The DPO4PWR Power Analysis Module adds measurements of power quality, switching loss, harmonics, ripple, modulation,
safe operating are a, and slew rate.
MSO4000 and DPO4000 Series Oscilloscopes User Manual 267
