Tektronix MSO4104 User Manual

Application Examples
Basic Strategy
First, you will display and acquire the bus s ignal by setting up the bus parameters and trigger. T hen, you will search through each
packet w ith the search/mark functions.
NOTE. Triggering on I
2
C, SPI, CAN, LI N, FlexRay, RS-232, RS-422, RS-485, UART, I
2
S, Left Justified, Right Justified, and TDM
bus signals requires use of an ap propriate DPO4EMBD, DPO4AUTO, DPO4AUTOMAX, or DPO4COMP, DPO4AUDIO Serial
Triggering and Analysis Module. Triggering on Pa rallel bus signals req uires use of an MSO4000 Series oscilloscope.
MSO4000 and DPO4000 Series Oscilloscopes User Manual 305
