Specifications
Specification
s
NOTE. This manual applies only to instruments calibrated with Version 1 RF Signal Path Gain Cal. or later. For instruments
calibrated with Version 0 RF Signal Path Gain Cal, use the Specifications and Performance Verification manual Tektronix part
number 077-10
30-XX available on the Tektronix web site.
(See page vii, De
termining RF signal path gain calibration version.)
The SignalVu
-PC software version must be version 3.5.0134 or greater.
All s pecifications are guaranteed unless labeled Typical. Typical specifications are provided for your convenience.
NOTE. Warranted characteristics that ar e checked in the Performance Verification are marked with a
symbol.
The perfo
rmance limits in this specification are valid within the following conditions:
The Signa
lVu-PC software v ersion is 3.5.0134 or greater.
The inst
rument was calibrated using Version 1 RF Signal Path Gain Cal. (See page vii, Determining RF signal path
gain calibration version.)
Operate the instrument in an environment that meets the temperature, altitude, and humidity characteristics listed in
these specifications.
The instrument must have been operating for a w arm-up period of a t least for 30 minutes (after being connected to the
PC, sta
rting the SignalVu-PC application, and SignalVu-PC is connected to the RSA306 instrument and continuously
acquiring data).
NOTE. The RSA306 does not fully power on until SignalVu-PC has established communication with the RSA306 and is
acqui
ring data.
The instrument must have had its signal–path–compensation routine last executed after at least a 30 minute w arm–up
period at an ambient temperature within ±2 °C of the current ambient temperature.
1 RSA306 Specifications and Performance Verification
